PLC Programming Advanced

$450.00

Out of stock

SKU

PLCE/32

The sixth in our PLC programming course collection is designed for people who want to use diagnostics on PLC hardware and develop and write PLC programs using binary and integer word instructions such as analogue, from more complex project specifications.

For information on course content, learning activities, and assessment click here

Details

PLC Application

This course is designed for those who have completed our PLC Programming Taster, PLC Programming Introduction, PLC Programming Software, and PLC Programming Essentials courses, or have an intermediate understanding of PLCs and programs and want to create more detailed projects using word PLC instructions. Additionally, use diagnostics to troubleshoot PLC hardware and work with engineering units, number systems and binary word structures to solve problems. PLC instructions used include bit, word, double word, and analogue. Each project uses a process description to develop a PLC ladder program solution. This is the same method used in industry to write PLC programs to a customer specification. Assessments are based upon the relevant performance and skills requirements described in the UEE Electrotechnology training package. This is the final course in our PLC Programming series. If you successfully complete all our PLC Programming courses you will have an advanced working knowledge of PLCs, PLC programming and applications to take you to the next level in the workplace.

Content

6 PLC Training Projects
6 Training Videos
Online Learning and Study Resources
Online Knowledge and Skills Quizzes
Scheduled Online Q&A Sessions
Certificate of Completion
Hrs to Complete - 60

Outcomes

Apply WHS/OHS practices
Download and install Rockwell CCW PLC software
Develop PLC programs from a detailed specification
Edit and modify PLC programs
Test and debug PLC programs
Converting between number systems
Use number systems, bit, analogue, and word instructions in programs
Use diagnostics and software considerations in a PLC program
Use PLC instructions
- Word, Double Word, Real, Scale, Math

Assessment

This course covers some of the outcomes described in the following national UEE Electrotechnology training package competencies:

UEECD0007 - Apply work health and safety regulations, codes and practices in the workplace
UEECD0051 - Use drawings, diagrams, schedules, standards, codes and specifications
UEECS0033 - Use engineering applications software on personal computers
UEEIC0013 - Develop, enter and verify discrete control programs for programmable controllers
UEEIC0015 - Develop, enter and verify word and analogue control programs for programmable logic controllers

and skill set:

UEESS00135 - Instrumentation - Programmable Control Systems Skill Set

More Information

More Information
Who Should Attend	Suitable for people with developing or existing PLC knowledge, including electricians, electrical technicians, engineers and maintenance staff seeking to build skills in PLC diagnostics, advanced instructions and practical automation applications.
Prerequisites	To complete this course, you should have finished PLC Programming Applications, or have suitable PLC programming experience, and be familiar with common Microsoft Windows tasks such as file management, navigation, s
Hours to Complete	The course requires about 60 hours to complete. Actual time may vary depending on learning pace, computer skills, and how much time is spent reviewing optional resources or practising the included activities.
Software Download	Participants receive links to download and install Rockwell Software Connected Components Workbench (CCW) Standard Edition (Free). CCW must be installed to access lessons, simulations, and course activities. Refer to Terms and Conditions for details.
Computer Hardware	A computer meeting the minimum specifications is required. A higher‑performance system will improve responsiveness when running CCW, simulations, and other course software used throughout the training.
Computer Requirements	Minimum specifications: Intel Core i5 2.4 GHz or equivalent, 8 GB RAM, 20 GB free disk space with at least 2 GB for the installer, and a Windows‑compatible pointing device such as a mouse or trackpad for accurate navigation.
Operating System	CCW supports 64‑bit Windows 10 and Windows 11 Professional or Enterprise. Microsoft .NET Framework 3.5 SP1 must be manually enabled or installed to ensure correct operation of CCW and related course software.
